ptfe fabric belt,harshima&oshima HarmonY fusing seamless belt

100% Satisfaction guaranteed or Your money back.

We will send the quotation to your email within 24 hours.

Product Description

Ruida PTFE fabric belt, ptfe conveyor belt, seamless belt,fusing seamless belt,endless belt. Welcome you purchase our standard products or send us your OEM requests.

Product Details

Quick Details

Weight: 165-780

Width: 1250-3500mm

Yarn Type: E-Glass

Weave Type: Plain Woven

Alkali Content: Alkali Free

Standing Temperature: -140-260℃

PTFE fiberglass endless conveyor belt

Seamless fusing machine belt:
PTFE fiberglass endless conveyor belt choose fine fiberglass and Kevlar as basic materials, knitted by special equipment and coated with fine PTFE so finally make one kind of special seamless fusing machine belt. Seamless fusing machine belt overcomes former problems of traditional joint fusing machine belt such as bad stability, ruptures, and deflecting for different girth on two sides at the joint. The using life of seamless PTFE Fusing Machine Belt are much longer than all kinds of joint PTFE Fusing Machine Belt.

2ply fusing machine belt:
PTFE fiberglass endless conveyor belt with static-resistance varnished cloth inside and tearing-resistance fiberglass cloth outside, 2ply belt has a great improvement on its intensity, long using life, well balanced thickness, excellent deflecting preventing capacity, smooth surface, it’s better for super thin fabric fusing.

Common seam joint fusing machine belt:
Seam joint fusing machine belt is made of fine material. The surface is smooth and luster and the price is competitive. It can substitute imported high price belts.

Our fusing machine belt features:
1. High temperature resistance and adherence resistance;
2. Good tensile strength, preventing deflecting;
3. Excellent capability of resistance of static;
4. mooth surface, more suits for super thin lining;
5. Flex fatigue resistance, durable, long using life;

PTFE Belting

Ruida manufactures various of belts with its material of smooth ptfe fabric,ptfe mesh, kevla, silicon rubber etc to custom specifications, depending on each customer’s individual needs. To help determine the best belt for your unique application, you need provide the following information for our experienced technical manager to discuss your requirement.

Ordering Your Ruida Belt
Whenever possible, have the following information available:

* Dimensions of belt: width and length
* Desired splice, edge reinforcement and tracking devices, where needed
* Pulley size and type
* Any special construction or instructions concerning the fabrication of your Ruida belt. In some cases of
complex fabrication,a print may be requested.

Choosing the Right Material
There are a number of factors to keep in mind when choosing the belting material for your application:

* Temperature Range – Our ptfe fabrics have the capabilities of withstanding -70°C- +260°C constant operating temperatures.
* Pliability – If the material is to track around pulleys that drive the belt, the diameter of the pulley is critical. The smaller the roller the more flexible the belt must be. Ruida’s thinner materials (0.010” and under) are more pliant than the heavier coated fabrics.
* Release Qualities – The surface finishes of our materials range from a rough, semi-porous finish to a super smooth surface. The release or fabric impression results desired will be a determining factor.
* Strength – Options to be considered are breaking, tensile and tear strength. How much of a load the belt carries, how fast it moves and how tightly it will be tensioned all must be considered.

Fabric Grades
Learn more about the various fabric grades available when constructing your belt.

Applications
Learn about the different applications for ptfe coated fiberglass ,silicon coated glass tapes, fabrics and belts.

Fabrication Options
Learn more about the many options available for constructing your Ruida conveyor belt.

Metallic Splices
	Alligator Splice Ruida offers #1A galvanized or #1A stainless steel alligator splices. These splices are the most durable and are the easiest to use. Belts utilizing alligator or clipper splices can be installed without taking machinery apart. A coverflap can be added to reduce heat transfer to your material.
	Clipper Splice stainless steel clipper splices. These splices are the most durable and are the easiest to use. Belts utilizing clipper and alligator splices can be installed without taking machinery apart. A coverflap can be added to reduce heat transfer to your material.
Non-Metallic Splices
	Peek Splice Peek splices are an ideal choice when metallic splices cannot be used. Either a peek splice or a smartloop splice should be chosen when maximum airflow is desired.
	Smartloop Splice Smartloop splices are an ideal choice when metallic splices cannot be used. Either a peek splice or a smartloop splice should be chosen when maximum airflow is desired.
	Fabric Notch Splice A fabric notch splice is similar to the alligator splice but completely eliminates the metal clip. It uses a PTFE Kevlar(R) material with a special pin for joining.
Endless Splices
	Butt Splice The ends of the belt are butted together and joined by sealing a strip of reinforcing fabric under the butted ends. Butt splices provide the smoothest belt surface at the joint and eliminate the step-down surface which is characteristic of the overlap splice.
	Overlap Splice This is the standard splice for most applications. Overlap splices, normally cut and overlapped on a 90, 60 or 45 degree angle, are also commonly used since they are more flexible when running on smaller diameter rollers. Standard overlap splices are 1".
	Scarfed Splice To prepare a scarfed splice, the ends of the belt are "scarfed", or sanded down and joined eliminating the double thickness at the splice which is characteristic of the overlap splice, and eliminates the need for a heat-sealed reinforcement at the splice characteristic of the butt splice.

Edge Reinforcements
RUIDA belts can be supplied with strips of heat-sealed film or fabric on one or both edges of your belt. This reinforcement serves a dual purpose; it reduces fraying of belt edges which rub on guiding rollers and it also provides the strongest possible anchor for guiding pins, snaps and grommets.

TFE-Film Edge, Heat-Sealed
TFE film edges are heat-sealed to the top and bottom of the edges of the belt for a 1/2" or 1" (standard)

surface. The TFE film is available in 3 mil, black or clear, or 10 mil tan (1" surface only).

Fabric Edge, Heat-Sealed
Six mil fabric is heat-sealed to the top and bottom of the edges of the belt for a 1" (standard) or 2" surface. Fabric edges are available either tan or black.

Fabric Edge, Sewn & Sealed
For extra reinforcement, our six mil heat-sealed fabric edge can also be sewn if desired. This reinforcement is commonly used on open mesh belting..

Two-Ply Belts
Two-ply belts are constructed of two plies of TFE-GLASS™, laminated together with staggered splices. This provides a smooth, continuous thickness along the entire belt length which guarantees a uniform seal in packaging and heat-sealing applications. The belts are typically available in widths of ½" – 3".
